The Jelly Toggle Switch - 4 Gang (Row)
The Jelly Toggle Switch - 4 Gang (Row)
Handmade to order, lead time: 1-2 weeks
Simple, tactile and unwaveringly traditional, our new Heritage Light Switches look as pretty as they sound. These Edwardian-style switches can be installed over standard British single or double back boxes with our Mahogany Finish or Primed Maple pattresses.
The pressed brass housings are made using traditional methods, as are the glazed and pressed ceramic bases. The combination of brass and ceramic makes these new deVOL toggle switches feel unlike any regular switch, they are authentic and really quite special. It’s always the little things that can make a finished room really charming. So many homes can be spoiled by white plastic switches, they seem to be a part of renovation that is often overlooked as unnecessary.
Product specification
Dimensions
| Width | Height | Depth | |
| Switches | 76 mm | 76 mm | 44 mm |
| Pattress | 102 mm | 372 mm | 12 mm |
Materials & Finish
| Base | Black or white glazed ceramic |
| Internal Casing | ABS plastic |
| Jelly Housing | Solid brass, finish varies |
| Pattress | Mahogany finish or primed maple |
| Heirloom Brass |
|
A smooth polished surface with a traditional warm aged brass colour. The tone will age and develop a rich patina over time and with use. |
| Aged Brass |
|
These switches have a mottled aged brass finish with a gentle satin sheen and will continue to develop a richer patina within the first few months of handling. |
| Oxidised Brass |
|
The switches are aged with a mottled organic pattern and are then oxidised black using an ageing solution before being gently buffed back with wire wool to reveal the warm bronze undertones. |
| Mahogany Finish |
|
A handmade sapele wood pattress, smoothly sanded and stained to a rich mahogany finish. |
| Primed Maple |
| A handmade maple wood pattress, smoothly sanded and painted in our 'Putty' shade primer, ready for you to apply your desired colour. |
Specification
| Module | 2 Way, Intermediate, Single Way Retract, Retract to Centre |
| Supply voltage | 240V 50Hz AC |
| Current rating | 20A |
| IP rating | IP2XD |
| Terminal capacities | 4 x 1mm2 (Flex), 4 x 1.5mm2 (Solid), 3 x 2.5mm2 (Solid), 2 x 4mm2 (Solid), 1 x 6mm2 (Solid) |
| Application | Suitable for standard British single or double back boxes. |
| Safety & compliance | Toggle switch conforms to BS EN 60669-1 when assembled to the appropriate plate and installed correctly. |
| Certified for use in the UK & Europe, UKCA & CE marked. |
| This product is handmade and assembled in the UK. |
Care & Maintenance
Metal finishes should only be cleaned with a soft, dry cloth. Harsh cleaners and abrasive pads will damage and remove the finish.
Always switch off the mains power before cleaning the fittings.
Sustainability
Our switches are all handcrafted and assembled in the UK. We make every effort to source our materials and components from local suppliers in the UK.
Almost all of our packaging is recyclable and our designers are constantly working with suppliers to make improvements in this area.
Please recycle your packaging in accordance with local regulations.
Delivery & Returns
Delivery
This item is subject to the following delivery charges:
| UK Mainland | £8.50 (per order) 1-2 working days |
| Highlands/Isles | £18 (per order) 1-3 working days |
| Europe | £35 (per order) 2-4 working days |
| Rest of World | £80 (per order) 3-5 working days |
You can view a full delivery quote for your basket and shipping address in the checkout. All charges shown include any applicable tax and duty.
All deliveries are made via a reliable tracked service. For UK orders, each item will be dispatched as soon as it is ready and should arrive within 1-3 working days.
International orders will be dispatched only when all items are ready and they should arrive within 3-5 working days. If you wish to receive individual items as soon as they are ready, please consider placing them as separate orders.
Returns
This item is eligible for return within 28 days of delivery.
Any items returned to us in the condition in which they were sent will be refunded in full, excluding any delivery fees and a 10% restocking fee.
We are unable to cover any return postage costs, or any loss or breakages that occur during the return process. We therefore recommend that returns are made using the original packaging with a tracked, insured and signed for service.
All returns are made to our UK workshops.
